Product
PCB Relay
41 small PCB Relay
  • 41 small PCB Relay

41 small PCB Relay

小巧型P.C.B.繼電器（3 - 5 - 8 - 12 - 16A）

Compact electromechanical PCB Relay

·Small size, 15.7mm high

·AC and DC coils

· 8mm、6 kV(1.2/50 μ s) Isolation, coil contact

·Anti flux penetration: standard is RT II, (RT III option)

全國免費咨詢熱線：0755-84552800



Specifications 41.52.6. xxx 41.61.6. xxx
Contact specifications
Contact configuration 2 CO (DPDT) 1 CO (SPDT)
Rated current / maximum peak current (in/imax) a 8/15 16/30

Rated voltage / maximum switching voltage (un/umax) V AC

 250/400 250/400
Rated load AC1 VA two thousand four thousand
Rated load ac15 (230 V AC) VA three hundred and fifty seven hundred and fifty
Single phase motor rating (230 V AC) kw zero point three seven zero point five five
Breaking capacity dc1:30/110/220 V A 8/0.3/0.12 16/0.3/0.12
Minimum switching load MW (v/ma) 500（5/100） 500（5/100）
Standard contact material AgSnO? AgSnO?
Coil specification
Nominal voltage (UN) V DC 5 - 12 - 24 5 - 12 - 24
Rated power (PN) w zero point six five zero point six five
Operating range DC （0.7…1.1）UN （0.7…1.1）UN
Minimum pulse width MS twenty twenty
Maximum pulse width s thirty thirty
